No Item Specification Unit Remark
1 Type TFT Color LCD Module
2 Diagonal Size 546.86 mm(21.53 inch) diagonal
3 Active Display area 476.64(H) 268.11(V) mm
4 Outline Dimension 495.6(H) x 292.2(V) x16.5(D) mm Typ. (Without Inverter)
5 Aspect Ratio 16:9
6 Pixel Number 1920 x RGB x 1080 pixel
7 Pixel Pitch 0.248(H) x 0.248(V) mm
8 Color arrangement RGB vertical Stripe
9 Color Depth 16.7M color (6bit with A-FRC)
10 Electrical Interface LVDS
11 Surface Treatment Hard coating(3H) & Anti-glare(Haze 25)
12 Operating Mode Normally White
13 Backlight Unit 4 CCFL (4 lamps)
14 Response Time Rising Time : 1.3 + Falling Time : 3.7 ms Typ.
15 Color Gamut Normal 72% Panel(CIE1931)
LGE Internal Use OnlyCopyright LG Electronics. Inc. All right reserved.
Only for training and service purposes
- 6 -
SPECIFICATION
NOTE : Specifications and others are subject to change without notice for improvement
.
4. Module Specification
LGD, LM215WF1-TLA1 ( P/N : EAJ60156901)
1. Application Range.
This spec sheet is applied to the 55 cm(21.5 inch) LCD
Monitor TV used LP92C chassis.
2. Specification
Each part is tested as below without special appointment
2.1 Temperature : 25 °C ± 5 °C (77 °F ± 9 °F),
CST : 40 °C ± 5° C
2.2 Relative Humidity : 65 % ±10 %
2.3 Power Voltage : Standard input voltage
(100 V - 240 V ~, 50 / 60 Hz)
• Standard Voltage of each products is marked by models
2.4 Specification and performance of each parts are followed
each drawing and specification by part number in
accordance with BOM .
2.5 The receiver must be operated for about 5 minutes prior to
the adjustment.
3. Test method
3.1 Performance : LGE TV test method followed.
3.2 Demanded other specification
Safety : CE, IEC specification, UL6500
EMC : CE, IEC, FCC Part 15Class A/ B
Safety : IEC/EN60065
EMI : EN55013
EMS : EN55020
