LG M2362D User Manual

111188
APPENDIX
01. Power k a 00 ~ 01
02. Aspect Ratio k c Refer to p. 119
03. Screen Mute k d 00 ~ 01
04. Volume Mute k e 00 ~ 01
05. Volume Control k f 00 ~ 64
06. Contrast k g 00 ~ 64
07. Brightness k h 00 ~ 64
08. Colour k i 00 ~ 64
09. Tint k j 00 ~ 64
10. Sharpness k k 00 ~ 64
11. OSD Select k l 00 ~ 01
12.
Remote control lock mode
k m 00 ~ 01
13. Treble k r 00 ~ 64
14.
Bass k s 00 ~ 64
15. Balance k t 00 ~ 64
16.
Colour Temperature k u 00 ~ 06
17. Auto Configure j u 01
18.
Tune Command m a Refer to p. 121
19.
Programme momory/Skip m b 00 ~ 01
20. Key m c Key Code
21. Control Backlight m g 00 ~ 64
22. Input select (Main) x b Refer to p. 121
Communication Parameters
A
Baud rate : 9600 bps
(
UART
)
A
Data length : 8 bits
A
Parity : None
A
Stop bit : 1 bit
A
Communication code : ASCII code
A
Use a crossed (reverse) cable.
Transmission
*
[Command 1] : First command to control the TV.
(j, k, m or x)
*
[Command 2] : Second command to control the TV.
*
[Set ID] : You can adjust the set ID to choose
desired monitor ID number in option
menu. Adjustment range is 1 ~ 99.
When selecting Set ID ‘0’, every con-
nected set is controlled.
Set ID is indicated as decimal (1~99)
on menu and as Hexa decimal
(0x0~0x63) on transmission/ receiv-
ing protocol.
*
[DATA] : To transmit command data.
Transmit ‘FF’ data to read status of
command.
*
[Cr] : Carriage Return
ASCII code ‘0x0D’
*
[ ] : ASCII code ‘space (0x20)’
[Command1][Command2][ ][Set ID][ ][Data][Cr]
OK Acknowledgement
* The TV transmits ACK (acknowledgement) based on
this format when receiving normal data. At this time, if
the data is in data read mode, it indicates present sta-
tus data. If the data is in data write mode, it returns the
data of the PC computer.
[Command2][ ][Set ID][ ][OK][Data][x]
Error Acknowledgement
* The TV transmits ACK (acknowledgement) based on
this format when receiving abnormal data from
nonviable functions or communication errors.
[Command2][ ][Set ID][ ][NG][Data][x]
Transmission / Receiving ProtocolCommand Reference List
*
When setting 15 ~ 22, a menu does not appear on screen.
COMMAND
1
COMMAND
2
DATA
(Hexadecimal)

LG M2362D Specifications

LCD Panel Specification

screen size	23” Class (23.0” diagonal)
resolution	1920 x 1080p
brightness	300 cd/m2 (Typical)
dynamic contrast ratio	50, 000:1
response time	5ms (Typical)
viewing angle	170º/160º
color supported	16.7M
aspect ratio	16:9
panel surface	Anti-Glare, 3H

Audio/Video Input/Outputs

hdmi	2
15 pin D-Sub	1
dvi-d	1
composite	1
scart	2
pc audio in	1
headphone out	1

Power

voltage, hz	100V ~ 240V, 56/75Hz
on mode power consumption	55W (Max)
standby mode power consumption	1W (Max)
off mode power consumption	0.5W (Max)

Dimensions & Weight

monitor with stand dimensions	21.7” x 16.5” x 8.7”
monitor without stand dimensions	21.7” x 14.9” x 2.6”
shipping dimensions	24.7” x 18.9” x 5.5”
monitor with stand weight	10.4 lbs
monitor without stand weight	9.7 lbs
shipping weight	13.7 lbs
