Exploded View
- 9 -
Copyright ©2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
7. Exploded View
7.1 HR Units
7.1.1 PRHR041/PRHR041A
135500B
249951
135500A
W4810A
W54100B
13 72 13B
55 21 1FB
55 21 1FA
W4810B
55 21 1G
W54100A
130401
137213A
352118
552204A
55 22 04B
149900
55 22 04B
552200
561410D56 14 10B
561410A
561410C
561410G561410F561410E
561410I56 14 10H
24 99 51
W6640B
W6640A
W4004
261704
268711
Part L/No. Sensor Location Remark
Thermistor 1
263230
SC out heatproof PVC : blue
Thermistor 2 SC in heatproof PVC : white
Thermistor 3 Liquid heatproof PVC : black
