- 24 -
Copyright © LG Electronics Inc. All rights reserved.
Only training and service purposes.
(5) Assemble/Fix the MAIN PCB + MODULE.
(6) Assemble/Fix the POWER + MODULE.
(7) Insert the HARNESS.
1) 14P HARNESS : POWER ⓐ <-> MODULE A
2) 15P HARNESS : POWER ⓑ <-> MODULE B
[Key Control Point]
* When assemble the PCB and Fix with the screw, be careful not to damage at PCB.
* Insert Harness into the WAFER until Connect sound is occurred.
3
3
1
3
3
3
3
3
3
3
3
A
B
3
5
2
3
ⓑ
ⓐ
4
CHASSIS ASSEMBLY
POWER SUPPLY ASSEMBLY
SCREW,MACHINE
HARNESS,SINGLE
HARNESS,SINGLE
FREE LGP48CX-20OP LCD YY -
BRH + 3MM 5.5MM SWCH18A FZMW N
20022HS-14B2 TO 20022HS-14B2_1
20022HS 15B2 TO 20022HS 15B2 L
MAIN EDX1C OLED48CX6LA MAIN EB
No
Description Qty
①
②
③
④
⑤
1
1
12
1
1
Specification
To Next Page
