LG OLED55B7A Safety And Reference

8
ENGLISH
Other Connections
Connect your TV to external devices. For the best
picture and audio quality, connect the external
device and the TV with the HDMI cable.
• > > > General > HDMI ULTRA HD
Deep Color:
- On : Support 4K @ 60 Hz (4:4:4, 4:2:2, 4:2:0)
- Off : Support 4K @ 60 Hz 8bit (4:2:0)
• If the device connected to Input Port also
supports ULTRA HD Deep Color, your picture
may be clearer. However, if the device doesn’t
support it, it may not work properly. In that case,
connect the device to a different HDMI port or
change the TV’s HDMI ULTRA HD Deep Color
setting to off.
• HDMI Audio Supported Format: DTS (44.1 kHz /
48 kHz), Dolby Digital / Dolby Digital Plus (32 kHz
/ 44.1 kHz / 48 kHz), PCM (32 kHz / 44.1 kHz / 48
kHz / 96 kHz / 192 kHz) (Depending upon model)
Magic Remote Functions
(Some buttons and services may not be provided
depending upon models or regions.)
When the message Magic remote battery is low.
Change the battery. is displayed, replace the
batteries. To install batteries, open the battery
cover, replace batteries (1.5 V AA) matching and
ends to the label inside the compartment, and
close the battery cover. Failure to match the correct
polarities of the battery may cause the battery to
burst or leak, resulting in fire, personal injury, or
ambient pollution. Be sure to point the remote
control at the remote control sensor on the TV.
To remove the batteries, perform the installation
actions in reverse.
This remote uses infrared light. When in use, it
should be pointed in the direction of the TV’s
remote sensor.
A
A
(Power) Turns the TV on or off.
You can turn your set-top box on or off by
adding the set-top box to the universal
remote control for your TV.
Number button Enters numbers.
- (Dash) Inserts a dash between numbers such as
2-1 and 2-2.
Accesses the saved channel list.
(Screen Remote) Displays the Screen Remote.
• Accesses the Universal Control Menu in some
regions.
* You can access the application or
Live TV channel by using the number buttons as
registered.
* SAP (Secondary Audio Program) Feature can
be enabled by pressing the key.

LG OLED55B7A Specifications

General

Screen Type	oled
Wall Mount	300mm x 200mm
Features	oled, pixel level dimming, perfect black, infinite contrast, billion rich colors, true color accuracy
Tuner	digital
Screen Size	54.6 inches, 55 inches
Resolution	4k (2160p)
Refresh Rate	60hz
HDR	yes
HDR Format	dolby vision
Built-In Speakers	yes
Surround Sound	dts studio sound, dts trusurround, dts truvolume, dolby digital plus
Speakers Output	40 watts
HDMI Ports	4
HDMI 2.1 Ports	0
HDMI ARC Ports	yes
USB Ports	3
Ethernet	yes
RF Antenna	yes
Bluetooth	yes
Network	built-in wi-fi, ethernet
Digital Optical Audio Outputs	1
Analog Audio Outputs	1
Component Video Inputs	0
Composite Video Inputs	1
DVI	0
SmartTV	webos
Streaming Services	hulu, netflix, youtube
Voice Assistant	other
Remote Control	magic
3D	no
Power Consumption	174 kilowatt hours
Depth with Stand	8.9 inches
Height with Stand	29.9 inches
Width with Stand	48.4 inches
Net Weight with Stand	45.2 pounds
Depth without Stand	1.9 inches
Height without Stand	27.9 inches
Net Weight without Stand	35.7 pounds
