- 18 -
Copyright ©
LG Electronics. Inc. All rights reserved.
Only for training and service purposes.
DISASSEMBLY GUIDE
FAB30016101 (M4*8mm, Black) 1EA
1. Disassemble Stand
2. Disassemble Power Cord Bracket
(1) Remove the screws (4EA)
(2) Grasp the top&bottom side( ) and pull in the direction of arrow( )
(3) Separate the stand

Other manuals for LG OLED55E7 series

Questions and Answers:

LG OLED55E7 series Specifications

General IconGeneral
Screen Size55 inches
Display TypeOLED
Smart TVYes
Operating SystemwebOS
HDMI Ports4
USB Ports3
Refresh Rate120Hz
AudioDolby Atmos
BluetoothYes
Wi-FiYes
Resolution3840 x 2160 (4K)
HDR SupportDolby Vision, HDR10, HLG
