Appendix 59
Appendix
6
General specifications
General
Power requirements Refer to the main label on the unit.
Power consumption
Refer to the main label on the unit.
Networked standby : 0,5 W
(If all network ports are activated.)
Dimensions (W x H x D) Approx. 330.0 mm x 685.0 mm x 344.0 mm
Operating temperature 5 °C to 40 °C
Operating humidity 5 % to 60 % RH
Inputs
Microphone (MIC IN) Sensitivity 20 mV (1 kHz), 6.3 mm jack x 2
HDMI OUT (video/audio) 19 pin (Type A, HDMI™ Connector ) x 1
Tuner
FM Tuning Range 87.5 to 108.0 MHz or 87.50 to 108.00 MHz
System
Frequency Response 250 to 20,000 Hz
Signal-to-noise ratio More than 80 dB
Dynamic range More than 80 dB
Bus Power Supply (USB)
5 V 0 500 mA
y Design and specications are subject to change without notice.
