3-13
USB FUNCTION
Check usb_5V
Display “NO USB”
YES
YES
Check usb_D+/D-
(R501,R502)
YES
Plug-in usb device
Check CN401
NO
NO
YES
Display “READ”
YES
Display “NO FILE”
YES
Check usb jack (JK501)
NO
Replace IC801
NO
Check IC801(pin116, 117)
Check usb audio
fi
le in usb device
(MP3, WMA
fi
le is playable)
YES
2. USB FUNCTION
25
27
Table of Contents
Default Chapter
2
Table of Contents
2
Section 1. General
3
Servicing Precautions
3
Esd Precautions
5
Service Information for Eeprom
6
Program Download Guide
7
Specifications
9
Section 2. Exploded Views
10
Cabinet and Main Frame Section
10
Mechanism Deck Section (CDM-340)
11
Speaker Section
12
Packing Accessory Section
13
Section 3. Electrical Part
14
Micom Part Check I
17
Fld Display Check
19
Power Amp Part Check
22
Tuner Function Check
24
Usb Function
26
Details and Waveforms on System Test and Debugging
27
Wiring Diagram
31
Block Diagrams
32
Circuit Diagrams
34
Circuit Voltage Chart
39
