LG RE-44NA14T User Manual

- 47 -
EXPLODED VIEW PARTS LIST
105 3680V00048B 3680V00048B LENS, SEKINOS SSM-100(50) LENS ASSEMBLY
107 4810V00780A 4810V00780A BRACKET, PRT ASSY MP03AA NON SSM-100 B CLENS+COUPLER+CPT
108 4810V00780B 4810V00780B BRACKET, PRT ASSY MP03AA NON SSM-100 G CLENS+COUPLER+CPT
109 4810V00780C 4810V00780C BRACKET, PRT ASSY MP03AA NON SSM-100 R CLENS+COUPLER+CPT
120 120-D38E 6400VA0015A SPEAKER
121 120-237C 120-237C SPEAKER,FULLRANGE C060T01K145A ESTEC 8 15/20 88 . 60X60 FULLRANGE
153 6150Z-1100E 6150Z-1100E DY(DEFLECTION YOKE), 2.5H 38KHZ L 400MM 07”” LGPLD RN-39NZ33H 6150Z-1100B
174 174-322G 174-322G POWER CORD, KUK JE VDE 2400MM HOUSING BLACK
300 3091V00B11A 3091V00A31G CABINET ASSEMBLY
301 3091V00595D 3091V00437D CABINET ASSEMBLY
302 3211V00088S 3211V00087S FRAME ASSEMBLY, FRONT LOWER RE-44NZ23RB .
303 4778V00011C 4778V00012C LEG, ROLLER CASTER
304 3350V00036A 3350V00028A SCREEN
305 3790V00687A 3790V00298Q FILTER(MECH)
310 5020V00674B 5020V00665B BUTTON, CONTROL ABS, HF-380 - 3KEY
311 3550V00213B 3550V00213A COVER, DECO
312 4810V00662A 4810V00670G BRACKET, CONTROL SP02PB HIPS 40AF
315 5020V00674A 5020V00665A BUTTON, CONTROL 4KEY NON
320 320-062F 320-062F SPRING, KNOB SPRING
330 5020V00675A 5020V00675A BUTTON, POWER RN-49NZ10HA NON 1KEY NON
340 6871VSMV16A 6871VSMV16A PWB(PCB) ASSEMBLY,SUB, PSW MP03AA M/I
350 6871VSMY16A 6871VSMY17A PWB,SUB CONT MP03AB M/I LED-CONTROL
360 6871VSMW96A 6871VSMW91A PWB,SUB CONT MP03AA M/I SUB-KEY
410 3809V00A64B 3809V00A15B BACK COVER ASSEMBLY
420 3809V00A65E 3809V00A16G BACK COVER ASSEMBLY
430 5018V00046B 5018V00028C MIRROR, AHSUNG MIRROR R2
501 4810V00752C 4810V00752C BRACKET, MAIN RU-40NZ60 MP03AA HIPS 407AF
503 4810V00844B 4810V00874B BRACKET, REAR AV MP03AB HIPS
510 6871VSMV08B 6871VSMV08B PWB,SUB CPT MP03AB M/I EXPORT NO HIGH VOLTAGE LABEL
520 6871VMN672C 6871VMN672U PWB,MAIN MP03AB M/I
530 6871VDM904A 6871VDM904A PWB,DEFLECTION MAIN2 MP03AB M/I 16:9, NARROW, 100MM EUROPE”
540 6871VSMC16A 6871VSMC16A PWB,SUB CVG MP03AB CONV-OUT M/I (PAL 2MODE)
550 6871VSMV80A 6871VSMV80A PWB,SUB DIGITAL MP03AB M/I PAL (W/O PC, W/ 1080I-ADJ) RE-44NA14T
570 6871VSMY14C 6871VSMY14U PWB,SUB MP03AB MICOM(PAL) W/ TXT, AUTO-CONV
590 6871VSMC17A 6871VSMC17A PWB,SUB CVG MP03AB D-CON M/I
600 6871VPMA27A 6871VPMA27A PWB,POWER SUB MP-03AB AC-INPUT M/I EUROPE
610 6871VSMV11P 6871VSMV11P PWB,SUB S/IN MP03AB SIDE-AV EU+ASIA 1000MM (WHITE+BEIGE) RE-49NZ23RB
620 6871VSMX19A 6871VSMX19A PWB,SUB P/AMP MP03AB M/I PRE-AMP (PAL) 1400MM (W/O HOLDER)
630 6871VSMC13A 6871VSMC13A PWB,SUB INTER MP03AA CVG-INTERFACE M/I
650 6871VSMB32B 6871VSMB32B PWB,SUB CVG SP-02PA/B 49” AUTO C/G RIGHT SENSOR
660 6871VSMB32E 6871VSMB32A PWB,SUB CVG SP02PB LEFT SENSOR
670 6871VSMB32F 6871VSMB32C PWB,SUB CVG SP02PB TOP SENSOR
680 6871VSMB32D 6871VSMB32D PWB,SUB CVG SP-02PA/B BOTTOM SENSOR
690 6871VSMV58B 6871VSMV58B PWB,SUB VM MP03AB EU,PAL
800 4410Z-A001L 4410Z-A001L FBT (FLY BACK TRANSFORMER), 4410Z-A001K 44” JW VE TYPE
810 180-836K FOCUS PACK W18-601-02 YINYANG 180-836H
No.
Part No.
44” 49”
Description
