Front Panel
Rear Panel
Subwoofer Connection1
Place the wireless subwoofer near the speaker and
follow steps below.
a Connect the power cord of wireless subwoofer
to the outlet.
b Turn on the main unit. :
The sound bar and wireless subwoofer will be
automatically connected. The subwoofer's
green LED turns on.
Subwoofer Connection Manually
a Reset the Subwoofer
If the green LED on the subwoofer blinks quickly,
skip this step and go to b
• Press and hold Pairing button for 5 seconds.
• The LED lights up alternately in red and green.
• Unplug the power cord. Then after the LED
turns off completely, plug in the power cord
in again.
When the reset is completed, the subwoofer's green
LED blinks quickly.
b Reset the sound bar
• Adjust volume to minimum. "MIN" appears on
display window.
• Press and hold
(Mute) button on the
remote control for 3 seconds.
"SUB - WF RESET" appears on display
window.
• Turn the sound bar’s power off, then back on
again whilst the subwoofer’s LED blinks green
When the connection is completed, you can see the
green LED on the subwoofer.
Keep the sound bar and the subwoofer 1m
or more away from other device (ex. wireless
router, microwave oven, etc.) to prevent any
wireless interference.
>1m
OPTICAL IN · · · · · · · · · · · Connect to an Optical device
PORTABLE IN ········ Connect to a Portable device
USB port ················· Connect to a USB device
HDMI IN ········· Connect to HDMI out on a device
HDMI OUT (TV ARC) ·············· Connect to a TV
··································Standby / On
·······························Selects Function
·························Adjusts Volume
The buttons are located on the rear panel.
