5-2
Copyright © 2021 LG Electronics Inc. All rights reserved.
Only for training and service purposes.
Rear AMP
SMPS
Wireless
RCN301
CN901
RJK301 SPK(RR/RL)
26P FFC
R
C
N
3
0
3
10P Harness
SPK terminal
WIRING DIAGRAM
