ENGLISH
10
Method of volume control port
(Depending on model)
• Cable Spec.
GND / UP / DOWN
Each Up / Down pin is
pulled to 3.3 V with CPU
GPIO.
CPU detects transition
from 3.3 V to GND level for
volume control.
Network
Wired network connection
(Depending on model)
This TV can be connected to a Pro:Centric server via the LAN port. After
making the physical connection, the TV needs to be set up for network
communication.
Connect the LAN port of the Modem or Router from Pro:Centric server
to the LAN port on the TV.
: Depending on model
Broadband Modem
Pro:Centric Server
Broadband Modem
Pro:Centric Server
Router
Broadband Modem
Connect the LAN port of the Modem or Router to the LAN port
on the TV.
Connect the LAN port of the PC to the AUX LAN port on the TV.
• Do not connect a modular phone cable to the LAN port.
• Since there are various connection methods, please follow
the specifications of your telecommunication carrier or
internet service provider.
