LG W2242T User Manual

NOTE
The order of icons may differ depending on the model (A13~A18 ).
On Screen Display(OSD) Selection and Adjustment
The following table indicates all the On Screen Display control, adjustment,
and setting menus.
To adjust the brightness,
contrast and gamma of the
screen
COLOR
POSITION
TRACKING
SETUP
Main menu Sub-menu A D Reference
PRESET
RED
GREEN
BLUE
To adjust the position of the
screen
To customize the color of
the screen
To customize the screen
status for a user's operating
environment
To improve the clarity and
stability of the screen
BRIGHTNESS
CONTRAST
GAMMA
LANGUAGE
OSD
HORIZONTAL
POSITION VERTICAL
sRGB
6500K
9300K
: Adjustable
A : Analog Input
D : Digital Input
To select or customize
desired image settings
FLATRON
F-ENGINE
MOVIE / TEXT
USER
NORMAL
HORIZONTAL
VERTICAL
CLOCK
PHASE
SHARPNESS
WHITE BALANCE
POWER INDICATOR
4:3 IN WIDE
FACTORY RESET
A10

LG W2242T Specifications

General

Pixel pitch	0.282 x 0.282 mm
Aspect ratio	16:10
Display diagonal	22 \
Display resolution	1680 x 1050 pixels
Vertical scan range	56 - 75 Hz
Horizontal scan range	30 - 83 kHz
Contrast ratio (typical)	-
Display brightness (typical)	250 cd/m²
Special features	sRGB, HDCP, Flatron f Engine, Intelligent Auto, Auto resolution, 4:3 in Wide (ARC)
Power requirements	90 – 264 Vac, 47 – 63 Hz
Display viewable area (HxV)	473.86 x 296.16 mm
HDCP	Yes
Certification	TÜV-Typ, CE, EPA Energy Star, UL, CSA, SEMKO, FCC-B, TCO03
Product color	Black
Compliance industry standards	DDC 2B
LED indicators	Stand-by
Tilt angle range	-5 - 20 °
Panel mounting interface	75 x 75 mm
Power consumption (standby)	0.3 W
Power consumption (typical)	22 W
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth (with stand)	210 mm
Height (with stand)	418 mm
Weight (with stand)	4700 g
Depth (without stand)	63 mm
Width (without stand)	516 mm
Height (without stand)	346 mm
