37
MOTOR/DAMPER
①①
Disassemble the back cover.
②②
Remove the bolt.
③③
Pull out the Rotor.
①①
Unscrew the 2 screws from the tub bracket.
②②
Remove the 6 bolts on the stator.
③③
Unplug the 2 connectors from the stator.
①①
Disassemble the damper hinges from the tub
and base.
②②
Separate the dampers.
※※
NOTE
• Once removed, replace the damper with
new one.
To Next Page
