10
INSTALLATION
Installation Place
Requirements
Before installing the appliance, check the following
information in order to install the appliance in a
correct place.
Unpacking Shipping Material
1
Remove the carton and the styrofoam packing.
2
Lift the washing machine and remove the base
packing.
3
Remove the tape securing the power supply
cord and drain hose.
4
Remove the inlet hose from the drum.
Installation Location
• Install the appliance on a flat floor of hard
material that is strong enough to support a fully
loaded appliance. (Allowable slope under the
appliance: 1º)
• Never try to level any uneven floor by putting
pieces of wood, cardboard or similar materials
under the appliance.
• If it is impossible to avoid positioning the
appliance next to a gas cooker or coal burning
stove, an insulation (85 X 60 cm) covered with
aluminium foil on the side facing the cooker or
stove must be inserted between the two
appliances.
• Ensure that when the appliance is installed, it is
easily accessible for a service technician in the
event of a breakdown.
• Additional clearance for the wall should have
10
cm
for the rear and
2 cm
for right and left side.
• This appliance must only be used for domestic
household purposes and should not be used
with movable home or house.
• Do not install this appliance on a raised surface
or platform, plinth or stand. It may cause injury
or serious malfunctioning.
Installing the Drain Hose
Before connecting the drain hose, check your drain
hose model and follow the instructions for that
model.
Installing the Drain Hose in a
Floor Drain
Positioning the Drain Hose
• The length
a
of the drain hose should not
exceed
300 cm
. Do not place the drain hose
b
more than
15 cm
above the floor.
• The outlet of the drain hose should not be
submerged in water.
300 cm
15 cm
