11
8
7
8.1
7.1
-10°C
+40°C
• The Manufacturer declines all responsibility for damage to electromechanical operator functioning caused by non-compliance to the storage
instructions given below.
• The electromechanical operator must be stored in closed, dry places, at room temperatures between –20 and +70°C and raised off the ground.
• Keep the electromechanical operator away from sources of heat and flames, that maybe cause malfunctions, fires or hazard situations.
ATTENTION: Important safety instructions. Follow all instructions carefully, incorrect installation may cause serious injury.
Before start installation we highly recommend reading the instructions and warnings contained in this manual carefully
(see the SAFETY INSTRUCTIONS AND WARNINGS Chap) and observing
the instructions it contains.
INSTALLATION
Instructions and warnings for installations
• Before start installation read the. SAFETY INSTRUCTIONS AND WARNINGS chapter carefully
• The PROFESSIONAL FITTER electromechanical operator is responsible to perform risk analysis and to regulate the automations
safety devices.
• The Fitter must check that the temperature range declared on the electromechanical operator is in accordance to the place in when the device
is installed.
•
Normally open/off buttons installed for the activation of the operator must be positioned so that they are within view of the gate but distant
from moving parts. Unless said commands
operate using keys, they must be positioned at a minimum height of 1.5m and not accessible to
• During installation, make constant reference to harmonised standards EN 12453 and EN12445.
• Ensure that the individual devices to be installed are compatible with the
electromechanical operator
. Do not proceed if even just one device is
• Ensure that the place of installation of the central unit is not prone to flooding, does not contain sources of heat or naked flames, fires or hazard
• During installation, protect control unit components in order to prevent liquids (e.g. rain) and/or foreign bodies (earth, gravel, etc) penetrating inside.
• Connect the control unit to a power supply line created in compliance with current regulations and earthed and fitted with a power supply sectioning switch.
• Wrapping materials must be disposed of in compliance with local regulations.
• Wear protective goggles when making holes for clamping.
In the event of work at heights of over 2m from the ground, for example for the installation of the indicator lamp or aerial, fitters must be equipped with
all other equipment required by law and the standards governing this kind of work.
to unauthorised persons.
unsuitable for the intended use.
situations in general.
with ladders, safety harnesses, protective helmet, and
TESTING AND TRIAL RUN
• The testing and trial run must be performed by a COMPETENT PERSON supervised and aided by a PROFESSIONAL FITTER.
It is the responsibility of the person who tests and sets up
the automation (of which the control unit is a part) to perform the checks
check conformity with the relevant legislation and standards,
in particular with EN standard 12445, which governs the methods for performing trials on gate automations and EN standard 12453
that specifies the performance requisites concerning safety of use.
• The testing and trial run are the most essential phases of installation for guaranteeing maximum operating safety.
• The checks and procedures for testing may also be used for routine checks on the automation and its devices.
• The automation may only be tested if a non-hazardous force tolerance has been set. Force tolerance must be adjusted to a
minimum value so as to exclude the danger of injury during closure.
• Adjust the maximum force in line with EN standard 12445.
• Never touch the gate or moving parts when they are in motion.
• Remain at a safe distance when the gate is in motion: only pass when the gate is completely open and immobile.
•
In the event of malfunctions (noisiness, jerky movements, etc.) suspend the use of the automation immediately: failure to obser
ve this rule may entail serious hazards, risks of accidents and/or serious
damage to the gate and the automation.
• Always remember that the following residual risks exist when the gate is in movement:
a) impact and crushing against the main closure edge (against the single leaf or between the two leaves);
b) impact and crushing in the opening area;
c) cshearing between the moving and the fixed guides and support during movement;
d) mechanical risks caused by movement.
required in accordance with the risks existing and to
During testing, ensure that the measurement of the gate’s impact force has been performed in accordance with EN standards 12445 and 12453.
• Check that the indications given in the SAFETY INSTRUCTIONS AND WARNINGS and INSTRUCTIONS AND INDICATIONS FOR INSTALLATION
chapters have been carefully observed.
• Ensure that the automation is correctly adjusted and that the protection and release systems are working correctly.
Testing
