Linear LDCO 863 User Manual

9
SETTING UP THE WALL STATION
This Wall Station allows operation of the light and door using the buttons, and when paired with the Linear
Android or iOS application you can operate garage doors, manage your family’s access, controls lights and it
informs you of people coming and going, from any location.
Requirements
To use with the app you will need:
• a Wi-Fi network with internet connectivity,
• a strong Wi-Fi signal in the garage where you are installing the Wall Station and
• an Android or iOS phone.
The Wall Station has two LEDs that convey information at a
glance.
LEDs on the Wall Station
The top LED provides information on the vacation mode.
The bottom LED indicates the state of the Wi-Fi connection
and device.
Test Wi-Fi Signal Strength with Your Smart Phone
If you have 2 or 3 bars on your phone from the Wi-Fi network, the signal is strong and you can proceed. If not,
use one of these options to extend your Wi-Fi network’s range.
• Move your Wi-Fi router closer to the garage.
• Purchase a Wi-Fi range extender.
Strong Wi-Fi signal
Wall Station will connect
to your Wi-Fi network.
Weak Wi-Fi signal
Wall Station may not connect
to your Wi-Fi network.
No Wi-Fi signal
Wall Station will not connect
to your Wi-Fi network.
The Wi-Fi wall station must receive a strong signal from your home’s Wi-Fi router to work.
Vacation Mode LED
ON
Normal operation. Vacation mode
disabled.
FLASHING Vacation mode enabled.
Wi-Fi Connectivity LED
RED Not connected to Wi-Fi.
YELLOW Performing update
GREEN Connected to Wi-Fi.

Linear LDCO 863 Specifications

General

Brand	Linear
Model	LDCO 863
Category	Garage Door Opener
Language	English
