EtherFast Cable/DSL Routers
68
Instant Broadband Series
67
4-Port Router Specifications
Model Number BEFSR41
Standards IEEE 802.3 (10BaseT), IEEE 802.3u (100BaseTX)
Protocol CSMA/CD
Ports (LAN) Four 10/100 RJ-45 switched ports
(WAN) One 10Base-T Ethernet RJ-45 port
for the cable or DSL modem
Speed (LAN) 10/100Mbps, (WAN) 10Mbps,
Cabling Type (10BaseT) UTP Category 3 or better
(100BaseTX) UTP Category 5 or better
Topology Star
LED Indicators Power,
(LAN) Link/Act, Full/Coll, 100
(WAN) Link, Act, Diag
Environmental Specifications
Dimensions 186mm x 154mm x 48mm (7.31” x 6.16” x 1.88”)
Unit Weight 13.4 oz. (0.42 Kg)
Power Input External, 9V AC, 1 Amp
Certifications FCC Class B, CE Mark Commercial
Operating Temperature 0°C to 40°C (32°F to 104°F)
Storage Temperature -20°C to 70°C (-4°F to 158°F)
Operating Humidity 10% to 85%, Non-condensing
Storage Humidity 5% to 90%, Non-condensing
• Straight-Through Cabling
• Cross-Over Cabling
Crimping Your Own Network Cables
