LIVARNO LUX Z31999 User Manual

6 GB/IE
LED solar spotlight
Intended use
The LED solar spotlight is intended to illuminate outdoor areas without elec-
trical connection, e.g. garden sheds, garages, etc. The LED solar spotlight
is not suitable for commercial use.
Parts description
1
Main unit
2
Spotlight
3
Motion sensor
4
Electrical connector
5
Switch (AUTO / OFF / PIR)
6
Solar cell with built-in twilight sensor
7
Screw (4 x 30 mm)
8
Wall plug (ø 6 mm)
9
Bracket (solar cell)
10
Rechargeable battery compartment
11
Locking screws
Technical Data
Operating voltage: 3.6 V
Rechargeable battery: 3 x NiMH battery 1.2 V , 600 mAh, AA
Light bulb: 10 LEDs, 0.06 W each (LEDs not replaceable)
Solar cell: amorphous, 8 x 8 cm, max. 5.4 V, max. 70 mA
Motion sensor: range: approx. 5–12 m,
detection angle: approx. 90° horizontal, 90°
vertical
Protection type: IP44 (splash-proof)
