Logik LFFD55S18 User Manual

7
INSTALLATION
9. Remove the pin from the upper hinge
and ip the hinge. Then re-attach the pin
to the hinge.
10. Carefully set the upper door back into
place. Re-attach the re-assembled
upper hinge on the opposite side of the
unit. Ensure the upper door is aligned
horizontally and vertically so that the
seals are closed on all sides before nally
tightening the upper hinge.
Middle hinge
unscrew screw
180˚
11. On the top panel move the blanking plate
to the side opposite the hinge.
8. After replacing the lower door, screw the
middle hinge back onto the opposite side
of the unit.
Ensure the lower door is aligned
horizontally and vertically, so that
the seals are closed on all sides
before nally tightening the hinge.
LFFD55S18_IB_RC_200716_grace.indd 7LFFD55S18_IB_RC_200716_grace.indd 7 16/7/2020 8:00 PM16/7/2020 8:00 PM

Logik LFFD55S18 Specifications

General

Brand	Logik
Model	LFFD55S18
Category	Freezer
Language	English
