LF 1090 Bariatric Patient Lift Owner’s Manual
LF1090 BARIATRIC PATIENT LIFT
SPECIFICATIONS
Note: All dimensions given in inches unless otherwise specified.
Base width
Open: 43"
Closed: 26"
Base height
(Clearance): 6"
Overall base length
50"
Lifting height range
Note: As measured from sling hooks.
Minimum: 27"
Maximum: 71"
Range: 35"
Mast height
50"
Weight capacity
600 lbs.
Rear locking caster size
4" diameter
Front caster size
4" diameter
Lifting mechanism
24 DC actuator
Battery charger
AC 110V / 220V to DC 24V 1 amp
15
