Remark :
1.For the Acceleration measurement, the Display will
show the indicator " ACC "
2.For the Velocity measurement, the Display will show
the indicator " VEL. "
3.For the Displacement measurement, the Display will
show the indicator " DISP p-p "
4.For general applications of industrial vibration
monitoring, select " Velocity " or " Acceleration "
typically.
5. After select the unit will be saved into the circuit with
default.
4-3 Function selection
Select the desired function ( RMS, Peak, Max HOLD )
by pressing the " Function Button " ( 3-3, Fig. 1 ).
continuously ( not release the button ), until the
Display will show the desiring function ( RMS, Max
HOLD, Peak ) , then release the " Function
Button " ( 3-3, Fig. 1 ). The detail procedures, please
refer to chapter 4-1, page 9. .
Remarks :
1.RMS measurement is intend to measure and
root means square ( RMS ) value.
The Display will show the indicator " RMS ".
2.Max HOLD measurement is intend to measure and
update the max. peak value.
The Display will show the indicator " MAX HOLD ".
Max hold reset procedures
Under execute the Max Hold function if press the
" LOGGER Button " ( 3-6, Fig. 1 ) continuously at least 5
seconds will clear the existing Max hold value.
11
