Lux Tools E-FS-1000/38 User Manual

28
Replacing the thread
It is possible to either replace the entire thread spool
or just the thread itself (►Spare parts– p.29).
Removing the thread spool
►P.4, item10
– Turn the screw(15) anti-clockwise.
– Detach the thread spool(16).
Replacing the thread in the thread spool
►P.4, item11
– Remove the thread remains.
– Hook two threads(17) in the holes(18) of the
spool.
►P.4, item12
– Wind threads tightly to the spool. Observe rota-
tion direction(19) of the spool. Threads must be
wound against the rotation direction.
►P.4, item13
– Press both threads into the opposing gaps(20).
Inserting the thread spool
►P.4, item14
– Feed both threads in the openings(21) of the
spool housing.
– Press the thread spool with spring carefully into
the spool housing(22). Pull the threads out
through the openings.
– Press and hold the thread spool and turn lightly.
The thread spool must remain in the pressed in
position!
– Position spool housing on shaft and screw tight
(►Fitting the filament spool– p.25).
Setting the thread to the right length
– Using one hand, press the underside of the
thread spool and pull both threads out until they
reach slightly further than the edge of the protec-
tive hood.
The threads will be cut automatically to the correct
length by the blade next time the unit is used.
Storage, transportation
Storage
– Store the tool in a dry and well ventilated place.
Transportation
– When dispatching, try to use the original pack-
aging, if possible.
Troubleshooting
Malfunctions are often caused by minor faults. You
can easily remedy most of these yourself. Please
consult the following table before contacting the
vendor. You will save yourself a lot of trouble and
possibly money too.
If you can’t fix the fault yourself, contact your nearest
vendor. Please be aware that any improper repairs
will also invalidate the warranty and additional costs
may be incurred.
Disposal
Disposal of the appliance
Appliances which are labelled with the adja-
cent symbol must not be disposed of in
household waste. You must dispose of such
old electrical and electronic equipment sep-
arately.
– Please check with your local authority about the
possibilities for correct disposal.
Through separate disposal you send old equipment
for recycling or for other forms of re-use. You will
thus help to avoid in somecases that damaging
material gets into the environment.
Disposal of the packaging
The packaging consists of cardboard and
correspondingly marked plastics that can
be recycled.
– Make these materials available for recycling.
Technical data
DANGER! Risk of injury! Unprofessional
repairs may mean that your unit will no
longer operate safely. This endangers you
and your environment.
Error/Fault Cause Remedy
The motor does not work. No power supply? Check the cable, plug, and the fuse.
Defective connecting cable? Contact your local vendor.
Threads don’t unwind. Thread used up? ►Replacing the thread– p.28.
Thread spool blocked? Remove the cause of the blockage
(►Removing the thread spool–
p.28).
Item number 467 812
Rated voltage 230V~, 50Hz
Wattage 1000W
Protection class II
Idle speed
• Impact knife
• Filament spool
8000min
-1
7500min
-1
Diameter of cutting area
• Impact knife
• Filament spool
230mm
380mm
Thread diameter
Filament spool 1.6mm
Noise output level (L
WA
)*
• Impact knife
• Filament spool
112dB(A)
96dB(A)
GB
467812_Trimmer.book Seite 28 Mittwoch, 27. April 2016 3:21 15
