Dear MAC AUDIO Customer,
The APM 4.0 car hi-fi power amplifier will enable you to satisfy your high demands on sound reproduction in your car. With its impressive
deep-bass power reserves, low harmonic content and neutral reproduction, the APM 4.0 takes car hi-fi to new heights. The amplifier is
characterized by low operating current, rapid switching capabilities and excellent temperature stability. Increased output power can be
achieved by switching two amplifier channels in an amplifier together in bridging mode. Experience and enjoy how this high-tech machine
perfectly reproduces magnificent sound.
Please read all of the owner‘s manual before installing and using the amplifier.
1. TECHNICAL DATA
APM 4.0
Max. output power (1 kHz sinus burst 2:8, B+=14.4V) 4 x 150 W / 2 x 400 W on 4 Ohm
Nominal output power (DIN 45 324, B+=14.4V) 4 x 50 W / 2 x 130 W on 4 Ohm
Max. output power (1 kHz sinus burst 2:8, B+=14.4V) 4 x 200 W on 2 Ohm
Nominal output power (DIN 45 324, B+=14.4V) 4 x 65 W on 2 Ohm
Loudspeaker impedance (stereo) 2 – 8 Ohm
Frequency response 5 – 50 000 Hz (-3 dB)
Total harmonic content (DIN 45 403) < 0.08% (1 kHz)
Stereo separation (IEC 581 ) > 60 dB (1 kHz)
Weighted noise distance (IEC A) > 100 dB
Input sensitivity LOW LEVEL INPUT 200 mV – 5 V
Input impedance LOW LEVEL INPUT 20 kOhm
Input sensitivity HIGH LEVEL INPUT 0,8 - 12V
Input impedance HIGH LEVEL INPUT 100 Ohm
Low-pass filter CH3/4 50 – 250 Hz, 12 dB per octave
High-pass filter 50 – 250 Hz, 12 dB per octave
Bass boost CH 3/4 0/6/12 dB at 45 Hz
Supply + 12 V (9 – 15 V), minus to ground
Fuse 2 x 20 A
Sizes (W x H x D) 310 x 53 x 253 mm
Weight 2.55 kg
SUBJECT TO TECHNICAL CHANGE
2. FEATURES
· Complementary push-pull final stage
· Automatic switching on/off via car radio
· Infinitely adjustable high pass and low pass filters
· Switchable bass equalizer
· Adjustable input sensitivity
· Bridgeable 4-/3-/2-channel mode
· Tri-mode
· Electronic protective circuit against short circuiting, DC offset and excess temperature
· Mute switch for suppressing switch-on crackle interference
· Low-level outputs (cinch jacks) for connecting a subwoofer amplifier
· High-level input for connecting to car radios without low-level output / cinch jacks
· Status indicator (green LED) and overload indicator (red LED)
