8-16
© Copyright Mahindra & Mahindra Ltd. 082014
8.28 Windshield Wipers
8.28.1 Wiper Control Stalk
The wipe/wash function can be activated only when the ignition is in “IGN” position.
A
Flick Wipe (MIST)
B Off
C
Intermittent (INT)
D
Low Speed (LO)
E
High Speed (HI)
8.28.2 Wiper Off
The wipe function is OFF when the wipe control stalk is in neutral position (B).
8.28.3 Flick-Wipe (Mist)
Push the wipe control stalk to position A for a flick-wipe, hold to operate the wipe
continuously (simultaneously lift the wiper stalk towards the steering wheel to
operate the wash). The stalk automatically comes back to position B when released.
8.28.4 Intermittent (INT) Mode
Intermittent (INT) wiping is selected when the wipe control stalk is pushed down to
position C. In the INT mode, the wiper operates on preset intervals of 4 sec.
The delay between each wipe can be programmed from 1 to 60 sec according to
the rain by the user.
Programming of the INT delay time is as follows;
• Turn the wiper stalk to position C, wiper will start wiping
• Turn the wiper stalk to OFF position, before wiper starts second wipe
• Turn the wiper stalk to position C again after the required delay and the same
delay will be programmed
• On keeping wiper ON position C, the wiper will wipe again with the programmed
delay
8.28.5 Low Speed Wiping
Push the wipe control stalk up to the position D to operate the wiper at a fixed low
speed.
8.28.6 High Speed Wiping
Push the wiper control stalk up to position E to operate the wiper at a fixed high
speed.
FEATURES AND CONTROL
