Mahindra 2014 Scorpio S6+ User Manual

2-18
© Copyright Mahindra & Mahindra Ltd. 082014
2.8 Technical Specifications
Technical Specifications
ENGINE - mHawk CRDe - BSIV
Displacement/Cubic Capacity
2179 cc
Type 4 Stroke, Turbocharged, Common Rail Direct Injection Engine
Bore x Stroke 85.0 X 96.0 mm
No of Cylinders
4 Inline
Max. Engine Output (kW @ rpm) 88.26 ± 2% kW @ 4000 rpm
Max. Torque (Nm @ rpm) 280.0 Nm @ 1800 to 2800 rpm
CLUTCH
Type Single Plate, Dry Type, Hydraulic Actuation
TRANSMISSION
Type Manual, Synchromesh in all Forward Gears
No. of Gears
5 Forward, 1 Reverse
GEAR RATIOS
I 3.777 : 1
II 2.214 : 1
III 1.425 : 1
IV 1.00 : 1
V 0.791 : 1
Reverse 3.559 : 1
TRANSFER CASE (4X4 ONLY)
Type
Electric Shift
GENERAL
