DECODING WIRE COLOUR
BASE COLOUR – Y – YELLOW
TRACER COLOUR – R - RED
WIRE CODE
B
BLACK
BL/L
BLUE
G
GREEN
Gr
GRAY
O
ORANGE
P
PINK
R
RED
Sb/S
SKY BLUE
V
VIOLET
W
WHITE
Y
YELLOW
Br
BROWN
WIRE COLOUR CODES
