Mahindra XUV 500 W8 XCLUSIVE User Manual

The repair methods given by the manufacturer in this document are based on the technical specifications, current at the time of release. The methods may be modified as a result of changes introduced by the manufacturer in the production of the various component
units and accessories from which the vehicles are manufactured. The reproduction, translation, transmission, in part of or whole of the present document,are prohibited without the prior written consent of Mahindra & Mahindra Ltd. The use of this document by any
person other than the trained personnel, at the Authorized Service Centre of Mahindra & Mahindra Ltd.,will amount to unauthorized use and shall be liable for penalty/prosecution© 2015 Mahindra & Mahindra Ltd.
WIRING MANUAL
MAN-00251
FEB 2015/Rev 2
XUV 500 XCLUSIVE
1. CONTROLLERS/FUSES/RELAYS - LOCATION
MAIN FUSE / RELAY BOX.............................................................................................03
2. INDIVIDUAL CIRCUITS
POWER SEAT................................................................................................................05
SUN ROOF....................................................................................................................06
REVERSE CAMERA.......................................................................................................07
FRONT HVAC................................................................................................................08
INTERIOR LIGHTING.....................................................................................................09
INFOTAINMENT............................................................................................................10
POWER WINDOW........................................................................................................11
3. GROUND SCHEME - LAYOUT
GROUND SCHEME - 1.................................................................................................12
GROUND SCHEME - 2.................................................................................................13
CONTENTS
2

Mahindra XUV 500 W8 XCLUSIVE Specifications

General

Brand	Mahindra
Model	XUV 500 W8 XCLUSIVE
Category	Automobile
Language	English
