6 ENGLISH

To install the blade, loosen the bolt counterclockwise on

the blade holder with the hex wrench.

With the blade teeth facing forward, insert the blade into

the blade holder as far as it will go. Make sure that the

backedgeofthebladetsintotheroller.Thentighten

the bolt clockwise to secure the blade.

►1. Bolt 2. Blade 3. Roller

To remove the blade, follow the installation procedure

in reverse.

NOTE:

• Occasionally lubricate the roller.

Hex wrench storage

►1. Hook 2. Hex wrench

When not in use, store the hex wrench as shown in the

guretokeepitfrombeinglost.

Adjusting roller (For models

4326/4326M/4327/4327M)

►1. Blade 2. Roller 3. Retainer 4. Hex wrench 5. Bolt

6. Base

Loosen the bolt on the back of the base with the hex

wrench. Move the retainer so that the roller contacts the

blade lightly. Then tighten the bolt to secure the base

and the retainer.

NOTE:

• Occasionally lubricate the roller.

Dust cover

►1. Dust cover

CAUTION:

• Always wear safety goggles even when operat-

ing the tool with the dust cover lowered.

Lowerthedustcovertopreventchipsfromying.

However, when making bevel cuts, raise it all the way.
