7
ENGLISH (Original instructions)
Explanation of general view
SPECIFICATIONS
• Due to our continuing program of research and development, the specifications herein are subject to change without
notice.
• Specifications may differ from country to country.
IMPORTANT SAFETY
INSTRUCTIONS
WARNING: When using an electric chain saw, basic
safety precautions should always be followed to reduce
the risk of fire, electric shock, and injury to persons,
including the following:
READ ALL INSTRUCTIONS.
1. Keep Work Area Clean
Cluttered areas invite injuries. Do not start cutting until
you have a clear work area, secure footing, and a
planned retreat path from the falling tree.
2. Consider Work Area Environment
Use extreme caution when cutting small size brush
and saplings because the slender material may catch
the saw chain and be whipped toward you or pull you
off balance. Do not operate a chain saw in a tree
unless specifically trained to do so. When cutting a
limb that is under tension be alert for spring back so
that you will not be struck when the tension in the
wood fibers is released. Don’t expose chain saw to
rain. Don’t use chain saw in damp or wet locations. Do
not use chain saw in presence of flammable liquids or
gases.
3. Guard Against Electric Shock
Prevent body contact with grounded surfaces. For
example: metal pipes, wire fences.
4. Keep Children Away
Do not let visitors contact chain saw or extension cord.
All visitors should be kept away from work area.
5. Store Idle Chain Saw
When not in use, chain saws should be stored in a dry,
and high or locked-up place - out of the reach of
children. When storing saw, use a scabbard or
carrying case.
6. Don’t Force Chain Saw
It will do the job better and safer at the rate for which it
was intended.
7. Use Right Tool
Cut wood only. Don’t use chain saw for purpose not
intended - for example - Don’t use chain saw for
cutting plastic, masonry non-wood building materials.
8. Dress Properly
Do not wear loose clothing or jewelry. They can get
caught in moving parts. Rubber gloves and non-skid
footwear are recommended when working outdoors.
Wear protective hair covering to contain long hair.
9. Use Safety Glasses
Also use safety footwear; snug fitting clothing;
protective gloves; hearing and head protection.
10. Carrying Saw
Carry the chain saw by the front handle with the saw
stopped, finger off the switch, the guide bar and saw
chain to the rear.
1. Loosen
2. Socket wrench
3. Chain cover
4. Guide bar
5. Adjusting pin
6. Sprocket
7. Cutter
8. Screwdriver
9. Saw chain
10. Tighten
11. Switch trigger
12. Oil button
13. Depress
14. Oil tank inspection window
15. Oil supply
16. Use this grip thumb below handle
17. Retreat
18. Direction of fall
19. Notch
20. 2 inches
21. Felling-back cut
22. Hinge
23. LIMB CUT
Keep work off ground
Leave support limbs until log is cut
24. Cut from top (overbuck) avoid
cutting earth
25. 2nd cut overbuck (2/3 diameter)
to meet 1st cut (to avoid pinching)
26. 1st cut underbuck (1/3 diameter)
(to avoid splintering)
27. 1st cut overbuck (1/3 diameter)
(to avoid splintering)
28. 2nd cut underbuck (2/3 diameter)
to meet 1st cut (to avoid pinching)
29. Stand on uphill side when cutting
because log may roll.
30. Front handle
31. Scabbard
32. TOP PLATE ANGLE
33. SIDE PLATE ANGLE
34. TOP FILING ANGLE
35. A top plate angle of 30° is ideal.
36. File the side plate to 85°
37. If you have filed the top and side
plate correctly the top filling angle
will be 60°- automatically.
38. Raker
39. File
40. Clean out this groove
41. Limit mark
42. Brush holder cap
Model
Chain speed per
minute
Length of guide
bar
Saw chain
Overall length Net weight
Pitch Gauge
5014B 400 m 335 mm 6.4 mm 1.27 mm 680 mm 5.6 kg
5016B 400 m 405 mm 9.5 mm 1.27 mm 750 mm 6.0 kg
