2
ENGLISH (Original instructions)
SPECIFICATIONS
Model 9561CH 9562CH 9563C 9564C 9565C
Depressed center wheel diameter 115 mm 125 mm 100 mm 115 mm 125 mm
Spindle thread M14 M14 M10 M14 M14
Rated speed (n) / No load speed (n
0
) 12,000 min
-1
Overall length 289 mm 299 mm
Net weight 2.1 kg 2.3 kg 2.1 kg 2.4 kg 2.3 kg
Safety class /II
Model 9561CVH 9562CVH 9564CV 9565CV
Depressed center wheel diameter 115 mm 125 mm 115 mm 125 mm
Spindle thread M14 M14 M14 M14
Rated speed (n) / No load speed (n
0
) 2,800 - 12,000 min
-1
Overall length 289 mm 299 mm
Net weight 2.2 kg 2.3 kg 2.4 kg 2.4 kg
Safety class /II
• Due to our continuing programme of research and development, the specifications herein are subject to change without notice.
• Specifications may differ from country to country.
• Weight according to EPTA-Procedure 01/2003
END202-6
Symbols
The following show the symbols used for the equipment.
Be sure that you understand their meaning before use.
･ Read instruction manual.
･ DOUBLE INSULATION
･ Wear safety glasses.
･ Only for EU countries
Do not dispose of electric equipment
together with household waste material!
In observance of European Directive
2002/96/EC on waste electric and
electronic equipment and its
implementation in accordance with
national law, electric equipment that
have reached the end of their life must
be collected separately and returned to
an environmentally compatible recycling
facility.
ENE048-1
Intended use
The tool is intended for grinding, sanding and cutting of
metal and stone materials without the use of water.
ENF002-2
Power supply
The tool should be connected only to a power supply of
the same voltage as indicated on the nameplate, and can
only be operated on single-phase AC supply. They are
double-insulated and can, therefore, also be used from
sockets without earth wire.
ENG905-1
Noise
The typical A-weighted noise level determined according
to EN60745:
Model 9562CH, 9562CVH, 9564CV
Sound pressure level (L
pA
) : 83 dB(A)
Sound power level (L
WA
) : 94 dB(A)
Uncertainty (K) : 3 dB(A)
Model 9565C, 9565CV
Sound pressure level (L
pA
) : 82 dB(A)
Sound power level (L
WA
) : 93 dB(A)
Uncertainty (K) : 3 dB(A)
Wear ear protection
ENG900-1
Vibration
The vibration total value (tri-axial vector sum) determined
according to EN60745:
Model 9562CH, 9562CVH
Work mode : surface grinding with normal side grip
Vibration emission (a
h,AG
) : 8.5 m/s
2
Uncertainty (K) : 1.5 m/s
2
