4 ENGLISH
FUNCTIONAL
DESCRIPTION
CAUTION:
-
ing or checking function on the tool.
and battery as shown in diagram when loading
Installing or removing battery
cartridge
1
2
3
1. Red indicator 2. Button 3. Battery cartridge
CAUTION:
removing of the battery cartridge.
when installing or removing battery car-
tridge. Failure to hold the tool and the battery
hands and result in damage to the tool and
To remove the battery cartridge, slide it from the tool
while sliding the button on the front of the cartridge.
To install the battery cartridge, align the tongue on the
battery cartridge with the groove in the housing and slip
it into place. Insert it all the way until it locks in place
with a little click. If you can see the red indicator on the
upper side of the button, it is not locked completely.
CAUTION:
Always install the battery cartridge fully until the red indi-
cator cannot be seen. If not, it may accidentally fall out of
cartridge does not slide in easily, it is not being
inserted correctly.
Battery protection system (Lithium-
ion battery with star marking)
1
1.
Lithium-ion batteries with a star marking are equipped
with a protection system. This system automatically
cuts off power to the tool to extend battery life.
or battery are placed under one of the following conditions:
The tool is operated in a manner that causes
it to draw an abnormally high current.
In this situation, release the trigger switch on
the tool and stop the application that caused
the tool to become overloaded. Then pull the
trigger switch again to restart.
If the tool does not start, the battery is over-
heated. In this situation, let the battery cool
before pulling the trigger switch again.
The remaining battery capacity is too low
and the tool will not operate. In this situation,
remove and recharge the battery.
Switch action
1
1.
