ENGLISH (Original instructions)
Explanation of general view
SPECIFICATIONS
• Due to our continuing program of research and development, the specifications herein are subject to change without
notice.
• Specifications and battery cartridge may differ from country to country.
• Weight, with battery cartridge, according to EPTA-Procedure 01/2003
Intended use
ENE039-1
The tool is intended for impact drilling in brick, concrete
and stone as well as for drilling without impact in wood,
metal, ceramic and plastic.
General Power Tool Safety
Warnings GEA010-1
WARNING Read all safety warnings and all
instructions. Failure to follow the warnings and
instructions may result in electric shock, fire and/or
serious injury.
Save all warnings and
instructions for future reference.
CORDLESS HAMMER DRIVER
DRILL SAFETY WARNINGS
GEB056-5
1. Wear ear protectors when impact drilling.
Exposure to noise can cause hearing loss.
2. Use auxiliary handle(s), if supplied with the tool.
Loss of control can cause personal injury.
3. Hold power tool by insulated gripping surfaces,
when performing an operation where the cutting
accessory may contact hidden wiring. Cutting
accessory contacting a “live” wire may make exposed
metal parts of the power tool “live” and could give the
operator an electric shock.
4. Hold power tool by insulated gripping surfaces,
when performing an operation where the fastener
may contact hidden wiring. Fasteners contacting a
“live” wire may make exposed metal parts of the
power tool “live” and could give the operator an
electric shock.
5. Always be sure you have a firm footing.
Be sure no one is below when using the tool in
high locations.
6. Hold the tool firmly.
7. Keep hands away from rotating parts.
8. Do not leave the tool running. Operate the tool
only when hand-held.
9. Do not touch the bit or the workpiece immediately
after operation; they may be extremely hot and
could burn your skin.
1. Red indicator
2. Button
3. Battery cartridge
4. Star marking
5. Indicator lamps
6. Check button
7. Battery capacity
8. Switch trigger
9. Lamp
10. Reversing switch lever
11. Speed change lever
12. Action mode changing ring
13. Adjusting ring
14. Graduation
15. Arrow
16. Sleeve
17. Groove
18. Hook
19. Screw
20. Bit holder
21. Bit
22. Blow-out bulb
Model DHP470 DHP480
Capacities
Concrete 13 mm
Steel 13 mm
Wood 38 mm
Wood screw 10 mm x 90 mm
Machine screw M6
No load speed
(min
-1
)
High (2) 0 - 1,550
Low (1) 0 - 400
Blows per
minute
High (2) 0 - 23,000
Low (1) 0 - 6,000
Overall length 199 mm
Net weight 1.5 kg 1.7 kg 1.5 kg 1.8 kg
Battery cartridge BL1415N
BL1430/BL1440/
BL1450
BL1815/BL1815N/
BL1820/BL1820B
BL1830/BL1840/
BL1840B/BL1850/
BL1850B
Rated voltage D.C. 14.4 V D.C. 18 V
To Next Page
