Removing or installing circular saw
blade
CAUTION: Be sure the circular saw blade is
installed with teeth pointing up at the front of the
tool.
CAUTION: Use only the Makita wrench to
install or remove the circular saw blade.
To remove the circular saw blade, press the shaft lock
fullysothatthecircularsawbladecannotrevolveand
use the hex wrench to loosen the hex bolt. Then remove
thehexbolt,outerange,circularsawbladeandring
(countryspecic).
2
1
4
3
►1. Shaft lock 2. Hex wrench 3. Loosen 4. Tighten
For tool without the ring
1
2
3
4
►1. Hex bolt 2.Outerange3. Circular saw blade
4.Innerange
For tool with the ring
1
2
3
4
5
►1. Hex bolt 2.Outerange3. Circular saw blade
4. Ring 5.Innerange
To install the circular saw blade, follow the removal
procedure in reverse.
For tool with the inner ange for other
than 15.88 mm hole-diameter saw blade
Theinnerangehasacertaindiameterprotrusiononone
side of it and a different diameter protrusion on the other side.
Chooseacorrectsideonwhichprotrusiontsintothesaw
bladeholeperfectly.Mounttheinnerangeontothemounting
shaftsothatthecorrectsideofprotrusionontheinnerange
facesoutwardandthenplacesawbladeandouterange.
12
3
4
5
►1. Mounting shaft 2.Innerange3. Circular saw
blade 4.Outerange5. Hex bolt
WARNING: BE SURE TO TIGHTEN THE HEX
BOLT CLOCKWISE SECURELY. Also be careful
not to tighten the bolt forcibly. Slipping your hand
from the hex wrench can cause a personal injury.
WARNING: Make sure that the protrusion "a"
on the inner ange that is positioned outside ts into
the saw blade hole "a" perfectly. Mounting the blade
on the wrong side can result in the dangerous vibration.
