10 ENGLISH
Ring
Only for Model DTW800
2
1
3
►1. Bracket 2. Ring 3. Screws
Theringisconvenientforhangingthetoolwithhoist.
First,placetheropethroughthering.Thenhangthe
tool up to the air with hoist.
CAUTION: Before using the ring, always
make sure that the bracket and ring are secured
and not damaged.
Installing hook
1
2
3
►1. Groove 2. Hook 3. Screw
Thehookisconvenientfortemporarilyhangingthetool.
Thiscanbeinstalledoneithersideofthetool.Toinstall
the hook, insert it into a groove in the tool housing
oneithersideandthensecureitwithtwoscrews.To
remove, loosen the screws and then take it out.
OPERATION
CAUTION: Always insert the battery cartridge
all the way until it locks in place. If you can see
the red part on the upper side of the button, it is not
locked completely. Insert it fully until the red part can-
not be seen. If not, it may accidentally fall out of the
tool,causinginjurytoyouorsomeonearoundyou.
Holdthetoolrmlyandplacetheimpactsocketover
theboltornut.Turnthetoolonandfastenfortheproper
fastening time.
Theproperfasteningtorquemaydifferdependingupon
the kind or size of the bolt, the material of the workpiece
tobefastened,etc.Therelationbetweenfastening
torqueandfasteningtimeisshowninthegures.
