17 ENGLISH
2
1
►1. Slotted screwdriver 2. Oil discharge hole
3. Insert the battery cartridge into the tool. Pull the
switchtriggertoowbuilt-updustorparticlesofftheoil
discharge hole by discharging chain oil.
4. Remove the battery cartridge from the tool.
Reinstall the sprocket cover and saw chain on the tool.
Replacing the sprocket
CAUTION: A worn sprocket will damage a
new saw chain. Have the sprocket replaced in this
case.
Beforettinganewsawchain,checktheconditionof
the sprocket.
1
2
►1. Sprocket 2.Areastobewornout
Alwaystanewlockingringwhenreplacingthe
sprocket.
1 2
►1. Locking ring 2. Sprocket
NOTICE: Make sure that the sprocket is installed
as shown in the gure.
Storing the tool
1. Clean the tool before storing. Remove any chips
and sawdust from the tool after removing the sprocket
cover.
2. Aftercleaningthetool,runitundernoloadtolubri-
cate the saw chain and guide bar.
3. Cover the guide bar with the guide bar cover.
4. Emptytheoiltank.
