Makita DUR181 Installation Manual

12
012415
Temporarily fix a Nylon cord at the notch shown in the
figure.
012416
Bring the Nylon cord through the Nylon cord eyehole in
the spool cover.
1
2
012417
After installing the Nylon cutting head, make sure that
the Nylon cord comes out by pressing the spool and
pulling the Nylon cord.
OPERATION
Attachment of shoulder strap
1
2
012395
Hook the shoulder strap in a hole in the front grip.
OPERATION
CAUTION:
• Do not cut high grass at a time. Cutting high
grass at a time near the root may cause the
trimmer motor spindle to be entangled by grass
which leads to the motor under overload, resulting
in damage to the trimmer.
012399
012400
1. Shoulder strap
2. Hook
1. Spool
2. Nylon cord

Makita DUR181 Specifications

General

Power source	Battery
Charging time	0.37 h
Battery voltage	18 V
Battery capacity	3 Ah
Product color	Black, Blue, White
Uncertainty K	1.5 m/s²
Rotational speed	7800 RPM
Secondary handle	Yes
Sound power level	88.5 dB
Vibration emission	2.5 m/s²
Sound pressure level	82 dB
Cutting diameter (max)	260 mm

Weight and Dimensions

Depth	257 mm
Width	267 mm
Length	1433 mm
Weight	3100 g
