2
SPECIFICATIONS
• Manufacturer reserves the right to change specifications without notice.
• Specifications may differ from country to country.
GENERAL SAFETY RULES USA002-2
(For All Tools)
WARNING:
Read and understand all instructions. Failure to follow all
instructions listed below, may result in electric shock, fire and/or
serious personal injury.
SAVE THESE INSTRUCTIONS
Work Area
1. Keep your work area clean and well lit.
Cluttered benches and dark areas invite acci-
dents.
2. Do not operate power tools in explosive
atmospheres, such as in the presence of
flammable liquids, gases, or dust. Power
tools create sparks which may ignite the dust
or fumes.
3. Keep bystanders, children, and visitors
away while operating a power tool. Dis-
tractions can cause you to lose control.
Electrical Safety
4. Double insulated tools are equipped with
a polarized plug (one blade is wider than
the other.) This plug will fit in a polarized
outlet only one way. If the plug does not
fit fully in the outlet, reverse the plug. If it
Model HP2070/HP2070F HP2071/HP2071F
Speed High Low High Low
Capacities
Concrete 20 mm (3/4”) ----- 20 mm (3/4”) -----
Steel 8 mm (5/16”) 16 mm (5/8”) 8 mm (5/16”) 16 mm (5/8”)
Wood 25 mm (1”) 40 mm (1-9/16”) 25 mm (1”) 40 mm (1-9/16”)
No load speed (RPM) 0 - 2,900/min. 0 - 1,200/min. 0 - 2,900/min. 0 - 1,200/min.
Blows per minute 0 - 58,000 0 - 24,000 0 - 58,000 0 - 24,000
Overall length 364 mm (14-3/8”) 362 mm (14-1/4”)
Net weight 2.4 kg (5.3 lbs) 2.4 kg (5.3 lbs)
