3
SPECIFICATIONS
• Due to our continuing program of research and development, the specifications herein are subject to change without
notice.
• Note: Specifications may differ from country to country.
Minimum Circuit Requirement: 15 AMPS
* A circuit breaker is preferred. Use only a fuse or circuit breaker that is the same rating as the branch circuit the air
compressor is operated on. If the air compressor is connected to a circuit protected by fuses, use time delay fuses.
IMPORTANT
Read the Safety Guidelines and ALL instructions carefully before operating.
www.makitatools.com
www.makita.ca
Model MAC100Q MAC210Q MAC320Q
MAX Output Power 350 W 800 W 1100 W
SCFM @ 90 PSIG 0.7 2.0 2.6
Cut-In Pressure 105 PSIG (0.72 MPa)
Cut-Out Pressure 135 PSIG (0.93 MPa)
Bore x Stroke x Qty 51 mm x 8 mm x 2 64 mm x 14 mm x 2 64 mm x 17 mm x 2
Voltage -Single Phase 120 V AC
Hz 60 Hz
Motor RPM 1,750 min
-1
Lubrication Oil-Less
Tank Size 1 gal (3.8 L) 2 gal (7.6 L) 3 gal (11.4 L)
Weight 12.5 kg (27.6 lbs) 20.5 kg (45.2 lbs) 23.8 kg (52.5 lbs)
Dimensions (L x H x W)
L: 328 mm (12-7/8”)
W: 370 mm (14-1/2”)
H: 282 mm (11-1/8”)
L: 441 mm (17-3/8”)
W: 429 mm (16-7/8”)
H: 347 mm (13-5/8”)
L: 456 mm (18”)
W: 481 mm (19”)
H: 348 mm (13-3/4”)
Outlet Max Pressure 135 PSIG (0.93 MPa)
CSA/US Listed Yes
