Makita ST113D User Manual

7 ENGLISH
CAUTION: After loading staples, make sure
that the sub magazine is surely closed. Falling
staplesoutofthemagazinemaycauseaninjuryto
the operator or bystander, especially when working in
high locations.
1. Remove the battery cartridge.
2. Pressthelockingleverandslidethesubmaga-
zine backward.
1
2
►1. Locking lever 2. Sub magazine
3. Load staples into the main magazine with their
feet facing up.
1
2
►1. Staples 2. Main magazine
4. After loading staples, push back the sub-maga-
zine in place until it clicks.
Toremovestaples,followtheinstallationproceduresin
reverse.
Hook
CAUTION: Do not hang the hook from the
waist belt. Dropping the stapler, which is caused by
the hook accidentally coming out of place, may cause
unintentionalringandresultinpersonalinjuries.
Thehookisconvenientfortemporarilyhangingthetool.
Thiscanbeinstalledoneithersideofthetool.
Toinstallthehook,insertitintoagrooveinthetool
housing on either side and then secure it with a screw.
Toremove,loosenthescrewandthentakeitout.
1
2
3
►1. Groove 2. Hook 3. Screw
OPERATION
Testing the safety system
WARNING: Make sure all safety systems are
in working order before operation. Failure to do
so may cause personal injuries.
4
1
2
3
►1.Trigger-lockbutton2. Switch trigger 3. Contact
element 4. Sub magazine
