ENGLISH
Explanation of general view
SPECIFICATIONS
• Due to our continuing programme of research and development, the specifications herein are subject to change without
notice.
• Specifications may differ from country to country.
• Weight, with battery cartridge, according to EPTA-Procedure 01/2003
Intended use
ENE033-1
The tool is intended for screw driving in wood, metal and
plastic.
SPECIFIC SAFETY RULES GEB012-3
DO NOT let comfort or familiarity with product (gained
from repeated use) replace strict adherence to impact
driver safety rules. If you use this tool unsafely or
incorrectly, you can suffer serious personal injury.
1. Hold power tool by insulated gripping surfaces,
when performing an operation where the fastener
may contact hidden wiring or its own cord.
Fasteners contacting a “live” wire may make exposed
metal parts of the power tool “live” and could give the
operator an electric shock.
2. Always be sure you have a firm footing.
Be sure no one is below when using the tool in
high locations.
3. Hold the tool firmly.
4. Wear ear protectors.
SAVE THESE INSTRUCTIONS.
WARNING:
MISUSE or failure to follow the safety rules stated in
this instruction manual may cause serious personal
injury.
IMPORTANT SAFETY
INSTRUCTIONS ENC007-4
FOR BATTERY CARTRIDGE
1. Before using battery cartridge, read all
instructions and cautionary markings on (1)
battery charger, (2) battery, and (3) product using
battery.
2. Do not disassemble battery cartridge.
3. If operating time has become excessively shorter,
stop operating immediately. It may result in a risk
of overheating, possible burns and even an
explosion.
4. If electrolyte gets into your eyes, rinse them out
with clear water and seek medical attention right
away. It may result in loss of your eyesight.
5. Do not short the battery cartridge:
(1) Do not touch the terminals with any
conductive material.
(2) Avoid storing battery cartridge in a container
with other metal objects such as nails, coins,
etc.
(3) Do not expose battery cartridge to water or
rain.
A battery short can cause a large current flow,
overheating, possible burns and even a
breakdown.
6. Do not store the tool and battery cartridge in
locations where the temperature may reach or
exceed 50 °C (122 °F).
7. Do not incinerate the battery cartridge even if it is
severely damaged or is completely worn out. The
battery cartridge can explode in a fire.
8. Be careful not to drop or strike battery.
9. Do not use dropped or struck battery.
SAVE THESE INSTRUCTIONS.
Tips for maintaining maximum battery life
1. Charge the battery cartridge before completely
discharged.
1. Button
2. Battery cartridge
3. Switch trigger
4. Lamp
5. Reversing switch lever
6. Bit
7. Sleeve
8. Bit-piece
9. Standard bolt
10. Fastening torque
11. Fastening time
12. Proper fastening torque
13. High tensile bolt
Model TD090D
Capacities
Machine screw 4 mm - 8 mm
Standard bolt 5 mm - 14 mm
High tensile bolt 5 mm - 10 mm
No load speed (min
-1
) 0 - 2,400
Impacts per minute 0 - 3,000
Overall length 155 mm
Net weight 0.92 kg
Rated voltage D.C. 10.8 V
