9
ENGLISH (Original instructions)
Explanation of general view
SPECIFICATIONS
• Due to our continuing program of research and development, the specifications herein are subject to change without
notice.
• Specifications may differ from country to country.
• Weight according to EPTA-Procedure 01/2003
Symbols
END108-6
The following show the symbols used for the equipment.
Be sure that you understand their meaning before use.
.....Read instruction manual.
.......................Warning! The cleaner may contain
hazardous dust.
.......................Never stand on the cleaner.
................ Only for EU countries
Do not dispose of electric equipment
together with household waste material!
In observance of the European Directive,
on Waste Electric and Electronic
Equipment and its implementation in
accordance with national law, electric
equipment that have reached the end of
their life must be collected separately and
returned to an environmentally
compatible recycling facility.
1. Suction force adjusting knob
2. Switch lever
3. Cap
4. Power supply cord
5. Holder
6. Base hook
7. Front cuffs
8. Hose
9. Caster
10. Stopper lever
11. FREE position
12. LOCK position
13. Tank cover
14. Powder filter
15. Damper
16. Prefilter
17. Tank
18. Mounting position marking
19. Water filter
20. Rubber holder
21. Paper pack
22. Cord hook
23. Press
24. Pipe holder
25. A section
26. Hooks
27. Press with a force and lower
28. Protrusion of the pipe holder
29. Groove
30. Hook
31. Holder plate
32. Polyethylene bag
33. Float
34. Float cage
35. Handle
36. Head
37. Cord hook
38. Straight pipe
39. Corner nozzle
40. Stopper
Model VC1310L / VC2510L / VC3210L
EU AU/NZ
GB
110V
GB
230V
CL AR/CH
Voltage Volt 230 - 240 230 - 240 110 230 - 240 220 230 - 240
Power consumption Watt 1,050 1,050 1,050 1,050 1,050 1,050
Connected load
for appliance socket
Watt
at symbol mode
2,400 1,200 600 1,900 2,200 1,100
Connected load
for appliance socket
Watt
at symbol mode
2,600 1,400 850 2,100 2,500 1,400
Total connected load Watt 3,450 2,250 1,650 2,950 3,250 2,150
Model VC1310L VC2510L VC3210L
Volume flow (air) 2.0 m
3
/min
Vacuum 22 kPa
Protection class 1
Type of protection IP X4 (splash-proof)
Recoverable capacity
Dust 13L 25L 32L
Water 7L 14L 27L
Dimensions (L x W x H)
366 mm x 334 mm x 420 mm 432 mm x 416 mm x 451 mm 552 mm x 398 mm x 685 mm
Net weight 9.6 kg 10.5 kg 14.5 kg
