Makita VC4210M User Manual

*) Optional accessories / Option depending on model
Original instruction
21
D
GB
F
NL
Makita VC4210M
6.2 Specifications
Makita VC4210M
EU/RU AU CH GB 230 V GB 110 V, 16 A GB 110 V, 25 A
Mains Voltage V 220-240 220-240 220-240 110-120
Mains frequency Hz 50/60 Power consumption / Rated current W 1200 1000 1000
Connected load for appliance socket W 2400 1100 1100 1700 – 1750
Total connected load W 3600 2300 2300 2900 1000 2750
Fuse A 16 10 13 16 25
Volume flow (air) max.
*)
l/min (m³/h) 4500 (270) 4200 (252)
Vacuum mbar (hPa) 250 (250) 230 (230)
Sound pressure level at a distance of 1 m, ISO 3744
dB(A) 62 ±2
Sound level dB(A) 60 ±2 Hand-arm vibration m/s² <2.5
Power cord length m 7.5
Power cord type
H07RN-F
3G1.5 mm²
H05RN-F 3G1.0 mm²
H07RN-F
3G1.5 mm²
H07BQ-F 3G1.5 H07BQ-F 3G2.5
Protection class I Type of protection IPX4 Radio interference suppression level EN 55014-1 Dust class M Tank volume l (UKgal) 42 (9.2)
Width mm (in) 385 (15.2) Depth mm (in) 575 (22.6) Height mm (in) 605 (23.8) Weight (net, most common application) kg (lb) 16.0 (35.3)
* measured at turbine Specifications and details are subject to change without prior notice.

Makita VC4210M Specifications

General

Power source	AC
Power control	Mechanical
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Maximum input power	1200 W
Annual energy consumption	- kWh
Cord length	7.5 m
Control type	Rotary
Dust container full indicator	-
Type	Drum vacuum
Cordless	No
Hose length	4 m
Cleaning type	Dry&wet
Dust capacity	34 L
Flexible hose	Yes
Hose diameter	32 mm
Product color	Blue, White
Number of wheels	4 wheel(s)
Dust container type	Combi
Liquid tank capacity	30 L
Number of 360° rotating wheels	2 wheel(s)
Airflow	75 l/s
Dust class	M
Proper use	Professional
Noise level	62 dB

Weight and Dimensions

Depth	565 mm
Width	385 mm
Height	605 mm
Weight	16000 g
