2 ENGLISH
ENGLISH (Original instructions)
SPECIFICATIONS
Model: XCU07
Overall length (without guide bar) 443 mm
(17-1/2″)
Rated voltage D.C. 36 V
Net weight 4.6 - 5.5 kg
(10.1 - 12.1 lbs)
Standard guide bar length 350 mm
(14″)
Recommended guide bar
length
with 90PX, 91PX 300 - 400 mm
(12 - 16″)
with 25AP 250 mm
(10″)
Applicable saw chain type
(refer to the table below)
90PX
91PX
25AP
Standard sprocket Number of teeth 6
*1
Pitch 3/8″
Chain speed 0 - 20 m/s
(0 - 1,200 m/min)
(0 - 3,940 ft/min)
Chain oil tank volume 200 cm
3
•
*1
When using 25AP saw chain, use with Sprocket 9 (optional accessory).
• Due to our continuing program of research and development, the specications herein are subject to change
without notice.
• Specications and battery cartridge may differ from country to country.
• The weight may differ depending on the attachment(s), including the battery cartridge. The lightest and heavi-
est combination, according to EPTA-Procedure 01/2014, are shown in the table.
Applicable battery cartridge
BL1815N / BL1820B / BL1830 / BL1830B / BL1840B / BL1850B / BL1860B
• Some of the battery cartridges listed above may not be available depending on your region of residence.
WARNING: Only use the battery cartridges listed above. Use of any other battery cartridges may cause
injury and/or re.
Saw chain, guide bar, and sprocket combination
Saw chain type 90PX
Number of drive links 46 52 56
Guide bar Guide bar length 300 mm
(12″)
350 mm
(14″)
400 mm
(16″)
Cutting length 275 mm
(10-7/8″)
330 mm
(13″)
370 mm
(14-1/2″)
Part No. 165245-8 165246-6 165247-4
Pitch 3/8″
Gauge 1.1 mm
(0.043″)
Type Sprocket nose bar
Sprocket Number of teeth 6
Pitch 3/8″
