Reference conditions
ISO reference conditions (according to ISO 3046-1: 2002; ISO 15550: 2002)
Intake air temperature T
r
°C 25
Barometric pressure p
r
kPa 100
Relative humidity Φr % 30
Cooling water temp. bef. charge air cooler T
cr
°C 25
Net calorific value LCV KJ/kg 42,700
Table 3: ISO reference conditions.
All data provided in this document is non-binding and serves informational purposes only. Depending on the
subsequent specific individual projects, the relevant data may be subject to changes and will be assessed and
determined individually for each project. This will depend on the particular characteristics of each individual
project, especially specific site and operational conditions.
MAN Diesel & Turbo
B 11 01 0
Fuel oil consumption for emissions standard
1693568-5.3
Page 2 (2)
L27/38S, L27/38
2014.06.06 - Tier I - Stationary
