Man L21/31 User Manual

Adress Hex Bit Meas.
Point
Description Unit Origin Signal
range
MW 32
MW 33
MW 34
MW 35
MW 36
MW 37
MW 38
MW 39
MW 40
MW 41
MW 42
MW 43
20
21
22
23
24
25
26
27
28
29
2A
2B
TE12
TE01
TE21
TE40
TE31
TE98-1
TE98-2
TE98-3
TE38
TE10
TE27-1
TE27-2
HT cooling water temperature engine outlet
LT cooling water temperature air cooler inlet
Lube oil temperature filter inlet
Fuel oil temperature engine inlet
Charge air temperature cooler outlet
Alternator windwing temperature L1
Alternator windwing temperature L2
Alternator windwing temperature L3
Ambient air temperature
HT cooling water temperature engine inlet
Alternator front bearing temperature
Alternator rear bearing temperature
CMS
CMS
CMS
CMS
CMS
CMS
CMS
CMS
CMS
CMS
CMS
CMS
0 - 200
0 - 200
0 - 200
0 - 200
0 - 200
0 - 200
0 - 200
0 - 200
0 - 200
0 - 200
0 - 200
0 - 200
MW 48 30 0
1
2
3
4
5
6
7
8
9
10
11
Sensor fault TE12 :
HT cool water temp. engine outlet
Sensor fault TE01 :
LT cool water temp. air cooler inlet
Sensor fault TE21 : Lube oil temperature filter inlet
Sensor fault TE40 : Fuel oil temperature engine inlet
Sensor fault TE31 : Charge air temp. cooler outlet
Sensor fault TE98-1 : Alternator windwing temp. L1
Sensor fault TE98-2 : Alternator windwing temp. L2
Sensor fault TE98-3 : Alternator windwing temp. L3
Sensor fault TE38 : Ambient air temperature
Sensor fault TE10 :
HT cool. water temp. engine inlet
Sensor fault TE27-1 : Alternator front bearing temp.
Sensor fault TE27-2 : Alternator rear bearing temp.
CMS
CMS
CMS
CMS
CMS
CMS
CMS
CMS
CMS
CMS
CMS
CMS
binary
binary
binary
binary
binary
binary
binary
binary
binary
binary
binary
binary
MW 64
MW 65
MW 66
MW 67
MW 68
MW 69
MW 70
MW 71
MW 72
MW 73
MW 74
MW 75
MW 76
40
41
42
43
44
45
46
47
48
49
4A
4B
4C
PT10
PT01
PT21
PT22
PT23
PT40
PT31
PT70
PT43
ZT59
ZT45
PT38
HT cooling water pressure
LT cooling water pressure
Lube oil pressure filter inlet
Lube oil pressure filter outlet
Lube oil pressure TC
Fuel oil pressure engine inlet
Charge air pressure cooler outlet
Start air pressure
Fuel oil pressure filter inlet
Alternator load
Fuel rack position
Ambient air pressure
Analog speed setpoint
CMS
CMS
CMS
CMS
CMS
CMS
CMS
CMS
CMS
CMS
CMS
CMS
CMS
MW 80 50 0
1
2
3
4
5
6
7
8
9
10
11
12
Sensor fault PT10 : HT cooling water pressure
Sensor fault PT01 : LT cooling water pressure
Sensor fault PT21 : Lube oil pressure filter inlet
Sensor fault PT22 : Lube oil pressure filter outlet
Sensor fault PT23 : Lube oil pressure TC
Sensor fault PT40 : Fuel oil pressure engine inlet
Sensor fault PT31 : Charge air press. cooler outlet
Sensor fault PT70 : Start air pressure
Sensor fault PT43 : Fuel oil pressure filter inlet
Sensor fault ZT59 : Alternator load
Sensor fault ZT45 : Fuel rack position
Sensor fault PT38 : Ambient air pressure
Sensor fault : Analog speed setpoint
CMS
CMS
CMS
CMS
CMS
CMS
CMS
CMS
CMS
CMS
CMS
CMS
CMS
binary
binary
binary
binary
binary
binary
binary
binary
binary
binary
binary
binary
binary
MAN Diesel & Turbo
B 19 00 0
Modbus list
3700054-4.0
Page 2 (5)
L27/38S, L16/24S, L21/31S, L16/24, L21/31, L27/38
2015.11.27
