2 - 66
Located at the rear of the lift truck, this device is used to attach a trailer. Its capacity is limited for each lift truck by the
Authorised Gross Vehicle Weight (A.G.V.W), tractive effort and maximum vertical force on the coupling point. This information
is given on the manufacturer's plate fixed to each lift truck (See chapter : IDENTIFICATION OF THE LIFT TRUCK in paragraph
: 2 - DESCRIPTION).
- To use a trailer, see current regulations in your country (Maximum running speed, braking, maximum weight of trailer, etc.).
- Verify the trailer's condition before using it (Tyre condition and pressures, electrical connection, hydraulic hose, braking
system…).
Do not tow a trailer or accessory which is not in perfect working order. Using a trailer in poor condition may effect the lift
truck's steering and braking, and hence safety.
If a third party helps in coupling or uncoupling the trailer, this person must be permanently visible to the driver and wait until
the lift truck has stopped, the handbrake is on and the engine is switched off before performing the operation.
NOTE : There is an OPTIONAL rear-view mirror which allows the lift truck to be approached more closely to the trailer ring.
A - TOWING PIN
(FIG
. A)
STANDARD
MT 732/932 Série A
MT 732 Turbo Série A
B - P
ROJECTING HOOK (FIG. B)
STANDARD
MLT 629/730 Série A
MLT 629/730 Turbo Série A
MLT 629/633/730 -120 LS Série A
MLT 633/730 LS Turbo Série A
MLT 633/730 -120 LS POWERSHIFT Série A
MLT 730 Turbo POWERSHIFT Série A
OPTION
MT 732/932 Série A
MT 732 Turbo Série A
COUPLING AND UNCOUPLING THE TRAILER
- To couple the trailer, position the lift truck as close as possible to the trailer ring.
- Put the handbrake on and switch off the IC engine.
- Remove the clip 1, lift the trailer pin 2 and place or remove the trailer ring.
Be careful not to get your fingers caught or crushed during this operation.
Do not forget to put clip 1 back in place.
When uncoupling, make sure that the trailer is supported independently.
TOWING PIN AND HOOK
2
1
A BB
MLT 629 . ..... MLT 633/730 . .....MT 732/932 . .....
1
2
2
1
