14 Part Number: 000015202 Rev 00 12/17
Operation Section 3
Operational Checks
GENERAL
Manitowoc ice machines are factory-operated and adjusted
before shipment. Normally, a newly installed ice machine
does not require any adjustment.
To ensure proper operation, always follow the Operational
Checks:
• when starting the ice machine for the first time
• after a prolonged out-of-service period
• after cleaning and sanitizing
NOTE: Routine adjustments and maintenance procedures
outlined in this manual are not covered by the warranty.
Blue Light
The blue light on the dispensing spout is energized when the
toggle switch is in the ICE position and the ice machine is
operational. If the light is not energized the ice machine will
not make ice. Refer to Section 5 Troubleshooting if the ice
machine has power and the light will not energize.
Toggle Switch
The toggle switch must be placed in the ICE position to make
ice.
Water Reservoir
The water reservoir must be 2/3 full of water and the water
sensing float must be up (switch closed) before the ice
machine will start.
WATER
SENSING
FLOAT
Ice Production
Allow the ice machine to produce ice for 15 minutes before
testing the dispense mechanism. This will ensure a sufficient
quantity of ice in the bin for dispensing.
OPERATION
1. Set Selector Switch (When Used)
Depress the button adjacent to the text.
• Select ICE for ice dispense only
• Select ICE/WATER for water and ice
• Select WATER for water only
2. Dispense
LEVER-ACTIVATED
Use glass or container to press dispenser arm backward.
Release the arm and the ice machine will stop dispensing.
TOUCHLESS CENTER-ACTIVATED
Place a glass or container underneath the dispensing spout
within 1" (2.5 cm) of the sensor. The ice machine will
automatically dispense. Remove the glass or container to
stop dispensing.
To Next Page
