Manitowoc Indigo NXT Series Technician's Handbook

Part Number: 000015431 Rev01 5/19 141
Diagnostics
Check real time data
1. Navigate to Menu/Service/Diagnostics/Inputs
2. Focus on Water LVL Low and Water LVL High display
• Not sensing displayed: indicates not touching water.
• Sensing displayed: Indicates touching water.
NOTE: If using reverse osmosis or deionized water, increase
sensitivity by moving the jumper over one pin (refer to
“Electronic Control Board” on page 200) and enabling
R.O. menu “Use less water with reverse osmosis”.
3. Disconnect the water level probe wiring harness from
the control board and ohm harness and water level
probe. Normal readings will show no resistance.
White
Black
Red
Short Probe
Ohm water Level Probe and Wiring Harness

Manitowoc Indigo NXT Series Specifications

General

Model	Indigo NXT Series
Ice Production	Varies by model
Ice Storage	Varies by model
Energy Efficiency	Energy Star certified models available
Refrigerant	R290 (varies by model)
Cooling System	Air-cooled or water-cooled (varies by model)
Condenser Type	Air-cooled, Water-cooled, or Remote
Touch Display	Yes, with intuitive interface
Control	Cleaning Alerts
Features	Self-cleaning, remote monitoring, energy-saving modes
Power Supply	Varies by model (typically 115V or 208-230V)
Dimensions (H x W x D)	Varies by model
Weight	Varies by model
