136 Part Number STH042 7/15
Tubing Schematic - U0190/U0240/U0310
HEAT EXCHANGER
AIR OR WATER
CONDENSER
DRIER
RECEIVER
(WATER COOLED ONLY)
EXPANSION
VALVE
HARVEST
SOLENOIDVALVE
EVAPORATOR
COMPRESSOR
STRAINER
